Generator Model HR-250GF – Technical Specifications

? Rated Voltage (V): 400/230

? Frequency: 50Hz/60Hz

? Power Factor: 0.8

? Type: 3P 4W

? Output Power (kW/kVA): 250/312.5

? Rated Current (A): 450

? Dimensions (mm): 2500 × 860 × 1700

? Gross Weight (kg): 1400

Diesel Engine Specifications

✔ Engine Model: Ricardo Steyr 6126ZLD-1

✔ Manufacturer: Weifang Ricardo

✔ Number of Cylinders: 6L

✔ Cylinder Arrangement: In-line

✔ Cycle: Four-stroke

✔ Aspiration: Turbocharged

✔ Compression Ratio: 16:1

✔ Bore × Stroke: 126mm × 135mm

✔ Displacement: 6.75 liters

✔ Rotation Direction: Clockwise (front view)

✔ Rated Power (kW/kVA): 260/325

✔ Generator Type: Mechanical

✔ Lubrication Oil Capacity (L): 20

✔ Rated Fuel Consumption (L/h): 33.5

Pump Types:

✔ Oil Pump Type: Single gear type

✔ Displacement/Speed (L/min/rpm): 62/2800

✔ Water Pump Type: Centrifugal type

✔ Pump Speed (rpm): 2800

✔ Injection Pump Type: In-line piston type

Operating Temperatures & Pressures:

✔ Oil Temperature: ≤ 95 ℃

✔ Cooling Water Temperature: ≤ 90 ℃

✔ Oil Pressure: 0.3 ~ 0.5MPa (≤ 0.01MPa at idle speed)

✔ Fuel Injection Pressure: 20 + 1.0MPa

Fuel Consumption at Different Loads:

✔ 100% Load (Prime Power): 218g/kW.h

✔ 75% Load (Prime Power): 207g/kW.h

✔ 50% Load (Prime Power): 220g/kW.h

Alternator Specifications

✔ Brand: Brushless/Brushed Alternator

✔ Model: HJI-250

✔ Rated Power (kW/kVA): 250/312.5

✔ Connection Type: 3-phase, 4-wire, Y-connection

✔ Number of Phases: 3

✔ Number of Bearings: 1

✔ Power Factor: 0.8

✔ Protection Level: IP23

✔ Altitude Capability: ≤ 1000m

✔ Excitation Type: Brushless/self-excited

✔ Insulation Class, Temperature Rise: H/H

✔ Telephone Influence Factor (TIF): < 50

✔ Voltage Regulation, Steady State: ≤ ±1%

✔ THF (Total Harmonic Factor): < 2%

✔ Alternator Efficiency: 95.20%
